PRODUCT DESCRIPTION
- Power: 2000 Max x 1 @ 2 Ohms, 1000 Max x 1 @ 4 Ohms
- Class A/B Topology:
- Class ?A? amplifiers have enormous amounts of current flowing through their output transistors with no audio signal.
- Class ?B? amplifiers have no current flowing through their outputs with no audio signal.
- Low & High Level Inputs:
- Low level (RCA) input is measured in voltages.
- High level ( wire) input is measured in wattages.
- Both carry signal from your receiver to your amplifier to your speakers.
- Variable Low-Pass Crossover:
- Subwoofers reproduce sound based on various low-range frequencies.
- You can set exact sound specifications for the bass frequency reproduction.
- Variable Bass Boost:
- Allows you to adjust the low bass within the boost range to your liking.
- Variable Gain Control:
- Adjusts the amount of signal coming from your receiver to your amplifier.
- Not for volume adjustment.
- Specs:
- Dimensions: 12.75? x 7? x 2.39?
- Weight: 6.5 lbs.
- Speaker Impedance: 2 to 8 Ohm
- THD @ RMS Output: 0.01%
- S/N Ratio: 103 dB
- Frequency Response: 9 Hz to 250 Hz
- Fuse Quantity: 2 25 Amp ATO Blade
- Planet Audio provides a Powerful 6 Year Platinum Online Dealer Warranty with purchase through Amazon.com.
- Professional installation is strongly encouraged for proper and safe functionality.
